1: The upright columns are built with oversized sections of cast iron
2: A large driving flywheel with a diameter of 2.2 meters
3: an integral direct push pre-tensioning device plus the secondary independent tensioning system, ensures the tensioning force to each diamond wire saw consistently with 200KG,tensioning wheels adopts swing motion type with high-strength aluminum alloy
4: the diameter of 800 mm guiding wheel
5: Automatic wedging system
6: Adopt single one design rubber in the wheel, plus male and femal interlock structure
7: Sprinkler system: upper inverted water spraying + left-right water spraying system
8: Control system with hydraulic station
