| model | TJXZ-60 | TJXZ-210 | |
| standard bucket | m³ | 0.22 | 0.91 |
| operating weight | kg | 5950 | 20800 |
| gradeability | ° | 35(70%) | 35(70%) |
| ground pressure | MPa | 0.032 | 0.047 |
| crowd force-arm | kN | 25.8 | 105 |
| breakout force-bucket | kN | 34.1 | 134 |
| engine model | 4TNV94L | A-6BG1T | |
| rated power | kw | 39.5 | 103 |
| rated speed | r/min | 2200 | 1900 |
| Length of standard crawler | L | 120 | 320 |
| flowrate | L/min | 55*2 | 210*2 |
| Max. swing speed | r/min | 9.6 | 13.2 |
| travel speed(low/high) | km/h | 2.4/4.0 | 3.5/5.5 |
| hydraulic oil tank capacity | L | 70 | 230 |
| working range | |||
| max. digging reach | mm | 6150 | 9920 |
| max.digging reach on ground | mm | 6050 | 9760 |
| max. digging depth | mm | 3800 | 6670 |
| max. vertical digging depth | mm | 3205 | 6050 |
| max. cuttong height | mm | 5810 | 9575 |
| max. dumping height | mm | 3960 | 6790 |
| dimensions | |||
| overall dimensions(L*H*W) | mm | 6115*1940*2660 | 9500*2990*2890 |
| overall width pf upper structure | mm | 1820 | 2625 |
| overall height of cab | mm | 2615 | 2830 |
| height of engine cover | mm | 1665 | 2270 |
| min.ground clearance | mm | 390 | 450 |
| tail swing radius | mm | 1830 | 2750 |
| distance between tunblers | mm | 1990 | 3660 |
| track length | mm | 2540 | 4460 |
| frame length | mm | 1900 | 2990 |
| track gauge | mm | 1500 | 2390 |
| length of standard crawler | mm | 400 | 600 |
After-sales Service Provided
Engineers available to service machinery overseas
